西安地区含水系统释水压密效应及微结构变化

董英; 张茂省; 刘洁; 张新社; 冯立

doi:10.19751/j.cnki.61-1149/p.2019.02.007

西安地区含水系统释水压密效应及微结构变化

董英^1,2,
张茂省^2, ,,
刘洁²,
张新社²,
冯立²

1. 西北大学, 陕西西安 710069;
2. 中国地质调查局西安地质调查中心/西北地质科技创新中心, 自然资源部黄土地质灾害重点实验室, 陕西西安 710054

基金项目:

国家重点研发项目（2018YFC1504700），国家自然科学基金重点项目（41641011、41530640），中国地质调查局项目（DDT20190463、DD20160261、DD20189270）联合资助

详细信息

作者简介:
董英(1981-),男,四川资阳人,高级工程师,主要从事水工环地质调查与研究。E-mail:dongy329@163.com

通讯作者:
张茂省(1962-),男,陕西咸阳人,研究员,博导,主要从事水工环地质调查与研究。E-mail:xazms@126.com

中图分类号: P641
计量
- 文章访问数: 1727
- HTML全文浏览量: 2
- PDF下载量: 1707
出版历程
- 收稿日期: 2019-04-03
- 修回日期: 2019-05-01
- 网络出版日期: 2022-07-28
- 发布日期: 2019-06-04

Water Release Compaction Effect and Microstructure Change of Aquifer System in Xi'an

1. Northwest University, Xi'an 710069, Shaanxi, China;
2. Key Laboratory for Geo-hazards in Loess Area, MNR, Xi'an Center of China Geological Survey/Northwest China Center for Geoscience Innovation, Xi'an 710054, Shaanxi, China

摘要

摘要: 西安地区诱发地面沉降地裂缝灾害最主要的因素是过量开采地下水。承压水地下水头下降引起的含水层骨架有效应力增加，粘性土释水压密一方面造成了地面沉降地裂缝灾害；另一方面引起含水层孔隙率、储水系数、渗透系数等水文地质参数的变化。笔者选取西安地裂缝最活跃的F4号地裂缝两侧钻孔岩心进行了压密CT扫描，获取了300 m以浅地层粘性土在不同压力（水头下降幅度）条件下的空隙大小的微结构变化，并建立了渗透系数与微结构变化耦合关系。结果显示：在地下水开采引起的土层应力增加过程中，大孔隙度、长孔隙度会随着压力增加而明显降低，地裂缝上盘和下盘含水层大孔隙分别降低了39.05%和9.22%，不利于水分在孔隙间运移，中小孔隙度基本保持不变或略有上升；渗透系数随压力的增加呈现出减小趋势，最大下降幅度为71.08%，且随深度增加含水层渗透系数减小幅度逐渐降低。研究结果对于科学评价和预测西安地区地面沉降地裂缝地质灾害具有指导意义。
- 粘性土 /
- 释水压密 /
- CT扫描 /
- 地面沉降
Abstract: In Xi'an city, the over-exploitation of groundwater is the most important factor for inducing land subsidence and ground fissures. The confined groundwater head increases the effective stress of the aquifer layer. The release compaction of cohesive soil water causes the land subsidence and ground fissures; it also results in the change of hydrogeological parameters, such as aquifer porosity, water storage coefficient and permeability coefficient. The borehole cores on both sides of the F4 ground fissure, served as the most active ground fissure in Xi'an city, are selected for the compacted CT scanning in this paper. Under the different pressures (head drawdown amplitude), the microstructure changes of the pores within 300m shallow clay have been obtained. And then, the coupling relationship between the permeability coefficient and microstructure change has been established. The results show that the large porosity and long porosity can decrease with the increasing pressure during the increase of soil stress caused by the groundwater exploitation. This is not conducive to the migration of water between pores. The macropores of the upper and lower aquifers of the ground fissure will decrease by 39.05% and 9.22%, respectively. The small and medium porosity is almost unchanged or only slightly increased. The permeability coefficient shows a decreasing trend with the increase of pressure. The aquifer permeability coefficient decreases with depth, the decline magnitude is gradually decreasing, and its maximum decrease is 71.08%. Thus, the research results have a guiding significance for scientific evaluation and prediction of land subsidence and ground fissure in Xi'an city.
- cohesive soil /
- water release compaction /
- CT /
- land subsidence

HTML全文

参考文献(16)

彭建兵,范文,李喜安,等. 汾渭盆地地裂缝成因研究中的若干关键问题[J]. 工程地质学报,2007,15(4):433-440.

PENG Jianbing, FAN Wen, LI Xi'an, et al.SOME KEY QUESTIONS IN THE FORMATION OF GROUND FISSURES IN THE FEN-WEI BASIN[J]. Journal of Engineering Geology,2007,15(4):433-440.

张茂省,董英,张新社,等. 地面沉降预测及其风险防控对策——以大西安西咸新区为例[J]. 中国地质灾害与防治学报,2013,24(4):115-118.

ZHANG Maosheng,DONG Ying,ZHANG Xinshe, et al. Prediction of land subsidence and Its mitigation methods——a case study in the new urban district of Xi'an-Xianyang[J]. The Chinese Journal of Geological Hazard and Control, 2013,24(4):115-118.

吴华山,陈效民,陈粲. 利用CT扫描技术对太湖地区主要水稻土中大孔隙的研究[J]. 水土保持学报, 2007, 21(2):175-178.

WU Huashan, CHEN Xiaomin, CHENCan.Study on Macropore in Main Paddy Soils in Tai-Lake Region With CT[J]. Journal of Soil and Water Conser Vation,2007,21(2):175-178.

赵冬, 许明祥, 刘国彬,等. 用显微CT研究不同植被恢复模式的土壤团聚体微结构特征[J]. 农业工程学报, 2016, 32(9):123-129.

ZHAO Dong,XU Mingxiang,LIU Guobin, et al. Characterization of soil aggregate microstructure under different revegetation types using micro-computed tomography[J]. Transactions of the Chinese Society of Agricultural Engineering,2016, 32(9):123-129.

郭晓明, 马腾, 陈柳竹,等. 污水灌溉下土壤孔隙特征的CT定量分析[J]. 地球科学-中国地质大学学报, 2015, (11):1896-1903.

GUO Xiaoming,MA Teng,CHEN Liuzhu, et al. Quantitative Analysis of Soil Pores under Sewage Irrigation Using Computerized Tomography[J]. Earth Science (Journal of China University of Geosciences) 2015, (11):1896-1903.

王宇, 李晓, 阙介民,等. 基于CT图像灰度水平的孔隙率计算及应用[J]. 水利学报, 2015, 46(3):357-365.

WANG Yu,LI Xiao,QUE Jiemin, et al. A porosity calculation method based on CT images and its application[J].Journal of Hydraulic Engineering, 2015, 46(3):357-365.

YU,Cheng. A fractal permeability model for bi-dispersed porous media[J]. International Journal of Heat & Mass Transfer, 2002, 45(14):2983-2993.

CARLSON., ROWE., R. A. Ketcham, et al. Applications of high-resolution X-ray computed tomography in petrology, meteoritics and palaeontology[J]. Geological Society London Special Publications, 2003, 215(1):7-22.

Al-Raoush,Willson. Extraction of physically realistic pore network properties from three-dimensional synchrotron X-ray microtomography images of unconsolidated porous media systems[J]. Journal of Hydrology, 2005, 300(1-4):44-64.

MOONEY. Three-dimensional visualization and quantification of soil macroporosity and water flow patterns using computed tomography[J]. Soil Use And Management, 2002, 18(2):142-151.
