Abstract: The Voisey's Bay Ni-Cu-Co sulfide deposit is hosted in a 1.34 Ga mafic intrusion that is part of the Nain Plutonic Suite in Labrador,Canada.The Ni-Cu-Co sulfide mineralization is associated with magmatic breccias that are typically contained in weakly mineralized olivine gabbros,troctolites and ferrogabbros,but also occur as veins in adjacent paragneiss.The mineralization is associated with a dyke-like body which is termed the feeder dyke.This dyke connects the shallow differentiated Eastern Deeps chamber in the east to a deeper intrusion in the west termed the Western Deeps Intrusion.Where the conduit is connected to the Eastern Deeps Intrusion,the Eastern Deeps Deposit is developed at the entry line of the dyke along the steep north wall of the Eastern Deeps Intrusion.The Eastern Deeps Deposit is surrounded by a halo of moderately to weakly mineralized Variable-Textured Troctolite (VTT) that reaches a maximum thickness above the ENE-WSW axis of the Eastern Deeps Deposit.At depth to the west,the conduit is adjacent to the south side of the Western Deeps Intrusion,where the dyke and intrusion contain disseminated magmatic sulfide mineralization.The Reid Brook Zone plunges to the east within the dyke,and both the dyke and adjacent paragneiss are mineralized.The Ovoid Deposit comprises a bowl-shaped body of massive sulfide where the dyke widens near to the present-day surface.It is not clear whether this deposit was developed as a widened-zone within the conduit or at the entry point into a chamber that is now lost to erosion.The massive sulfides and breccia sulfides of the Eastern Deeps are petrologically and chemically different when compared to the disseminated sulfides in the VTT; there is a marked break in Ni tenor (Ni content in 100% sulfide,abbreviated to Ni100) and Ni/Co of sulfide between the two.The boundary of the sulfide types is often marked by strong sub-horizontal alignment of heavily digested and metamorphosed paragneiss fragments,development of barren olivine gabbro,and by a change from typically massive sulfides and breccias sulfides into more typical variable-textured troctolites with heavy to weak disseminated sulfide.Sulfides hosted in the feeder dyke tend to have low metal tenors (Ni100=2.5%-3.5%); sulfides in Eastern Deeps massive and breccia ores have intermediate Ni tenors (Ni100=3.5%-4%) and disseminated sulfides in overlying rocks have high Ni tenors (Ni 100=4%-8%).Conduit-hosted mineralization and mineral zones in the paragneiss adjacent to the Reid Brook Deposit tend to have lower Ni tenor than the Ovoid and Eastern Deeps Deposits.The tenor of mineral hosted in the country rock gneisses tends to be the same as that developed in the conduit; the injection of the sulfide into the country rocks likely occurred before formation of monosulfide solid solution.The Ovoid Deposit is characterized by coarse-grained loop-textured ores consisting of 10cm-2msized pyrrhotite crystals separated by chalcopyrite and pentlandite.A small lens of massive cubanite surrounded by more magnetite-rich sulfide assemblages represents what appears to be the product of in-situ sulfide fractionation.Detailed exploration in the area between the Reid Brook Zone and the Eastern Deeps has shown that these intrusions and ore deposits are connected by a branched dyke and chamber system in a major westeast fault zone.The Eastern Deeps chamber may be controlled by graben-like fault structures,and the marginal structures appear to have controlled dykes which connect the chambers at different levels in the crust.The geological relationships in the intrusion are consistent with emplacement of the silicate and sulfide laden magma from a deeper sub-chamber (possibly a deep eastward extension of the Western Deeps Intrusion where S-saturation was initially achieved).The silicate and sulfide magmas were likely emplaced through this conduit into the Eastern Deeps intrusion as a number of different fragment laden pulses of sulfide-silicate melt that evolved with different R factors and in response to some variation in the degree of evolution of the parental magma.S isotope and S/Se data coupled with geological evidence point to a crustal source for the sulfur,and the site of equilibration of mafic magma and crustal S is placed at depth in a sulfidic Tasiuyak Gneiss.The structural control on emplacement of small intrusions with transported sulfide is a feature found in different nickel sulfide deposits around the world.Champagne glass-shaped openings in sub-vertical chonoliths are a common morphology for this deposit type (e.g.the Jinchuan,Huangshan,Huangshandong,Jingbulake,Limahe,Hong Qi Ling deposits in China,the Eagle deposits in the United States,and the Double Eagle deposit in Canada).Some of the structures of the Midcontinent Rift of North America also host Ni-Cu-(PGE) deposits of this type (e.g.the Current Lake Complex in the Quetico Fault Zone in Ontario,Canada and the Tamarac mineralisation in the Great Lakes Structural Zone of the United States).Other major nickel deposits associated with flat structures adjacent to major mantle-penetrating structures include the Noril'sk,Noril'sk II,Kharaelakh,NW Talnakh,and NE Talnakh Intrusions of the Noril'sk Region of Russia,the Kalatongke deposit in NW China,and Babel-Nebo in Western Australia.These deposits are all formed in mantle-penetrating structural conduits that link into the roots of large igneous provinces near the edges of old cratons.
