LA-ICP-MS Zircon U-Pb Chronology and Geological Implications of Sikeshu Stitching Pluton in the North Tianshan Suture Zone, Xinjiang
-
摘要: 四棵树岩体位于北天山缝合带中，是侵入依连哈比尔尕岛弧带中最大的一个花岗岩体，具有“钉合岩体”的构造意义。组成该岩体的岩石类型较多，大体上可分为3个侵入期次，依次为石英闪长岩和花岗闪长岩、二长花岗岩和钾长花岗岩、花岗斑岩；其中第二侵入期次构成了该岩体的主体。岩石SiO2含量为57.85%～74.28%，K2O含量为1.95%～5.25%，Na2O含量为3.00%～4.50%，整体表现为高K、Ca碱性特征。∑REE=113.91×10-6～169.47×10-6，（La/Sm）N 为1.77～3.16，（Gd/Yb）N为1.33～2.12，（La/Yb）N为3.41～5.64，δEu为0.37～0.82，表现为轻稀土元素富集的右倾型特征；岩石具有Nb、Ta、Eu的亏损以及Th、Zr、Hf相对富集。通过形成环境判别，第一期石英闪长岩和花岗闪长岩大部投在火山弧环境，板块碰撞前—后碰撞隆起阶段；第二期二长花岗岩和钾长花岗岩大部投在后碰撞阶段；第三期花岗斑岩主要投在晚造山阶段。通过LA-ICP-MS对该岩体中石英闪长岩、二长花岗岩和钾长花岗岩进行较为系统的锆石U-Pb测年，得出其加权平均年龄分别为（324.1±4.3）Ma、（314.9±4.1）Ma、（311.5±3.9）Ma。结合前人得出的巴音沟蛇绿岩中辉长岩的（344±3.4）Ma年龄，可初步得出北天山缝合带的形成时代应该为344～311.5 Ma，碰撞造山作用主要发生在324～311 Ma，随后进入后碰撞伸展阶段，而四棵树岩体3期侵入岩可能分别代表了北天山造山带俯冲汇聚-碰撞-陆内造山各阶段构造-岩浆作用的产物。
-
关键词:
- 高K、Ca碱性花岗岩 /
- 后碰撞 /
- 钉合岩体 /
- 四棵树 /
- 北天山缝合带
Abstract: Sikeshu granitic pluton is located in the North Tianshan suture zone, the biggest granitic body which intrudes the Yilianhabierga island arc belt, and has tectonic significance as one stitching pluton. Sikeshu pluton is composed of various types of rocks generally formed in three intrusive periods. In the first period, the pluton rocks are quartz diorite and granodiorite, while in the second period the major compositions are monzogranite and K-feldspar granite, and in the third period the pluton is made of granite porphyry. Noticeably, rocks occurred in the second intrusive period constitute the main body of the pluton. On the whole, the rocks are featured by high-K calc-alkaline characteristics, with SiO2 content varying between 57.85 and 74.28 wt.%, K2O content from 1.95 to 5.25 wt.%, and Na2O content from 3.00 to 4.50 wt.%. The total REE content is between 113.91×10-6 ppm and 169.47×10-6 ppm. In addition, the values of (La/Sm)N, (Gd/Yb)N and (La/Yb)N fluctuate from 1.77 to 3.16, 1.33 to 2.12, and 3.41 to 5.64 respectively, showing a right-inclined distribution pattern characterized by weakly negative Eu anomalies with δEu value from 0.37 to 0.82. Moreover, the rocks are enriched in Th, Zr, Hf and depleted in Nb, Ta and Eu. In terms of deformation environment, quartz diorite and granodiorite of the first period mainly fall into the volcanic arc area of the pre-collision to the post-collision stage; rocks of the second period, namely monzogranite and K-feldspar granite, mainly formed in the post-collision stage; and graniteporphyry in the last period occurred in later orogenic stage. LA-ICP-MS zircon U-Pb dating results of quartz diorite, monzogranite and K-feldspar granite are 324.1±4.3 Ma, 314.9±4.1 Ma and 311.5±3.9 Ma. Considering the age of Bayingou ophiolite, which is 344±3.4 Ma according to previous researches, we can conclude that the suture zone of North Tianshan formed between 344 to 311.5 Ma and the major collision orogenic process took place from 324 to 311 Ma, and then the suture moved into the post-collision stage after 311 Ma. To some extent, the three intrusive rock units of Sikeshu granitic pluton may be representative products of three tectonic-magmatic stages, which are subduction, collision and intracontinental orogenic of North Tianshan orogenic belt. -
-
韩宝福,季建清,宋彪,等. 新疆喀拉通克和黄山东含铜镍矿镁铁-超镁铁杂岩体的SHRIMP锆石U-Pb年龄及其地质意义[J]. 科学通报,2004,49(22):2324-2328. Han Baofu,Ji Jianqing,Song Biao,et al. SHRIMP U-Pb zircon age of the mafic-ultramafic rocks and geological significance in Kalatongke and Huangshan,Xinjiang [J]. Chinese Science Bulletin,2004,49 (22): 2324-2328 (in Chinese with English abstract).
韩宝福,郭召杰,何国琦. “钉合岩体”与新疆北部主要缝合带的形成时限[J]. 岩石学报,2010,26 (8): 2233-2246. Han Baofu,Guo Zhaojie,He Guoqi. Timing of major suture zones in North Xinjiang,China: Constraints from stitching plutons [J]. Acta Petrologica Sinica,2010,26 (8): 2233-2246 (in Chinese with English abstract).
何国琦,朱永峰.中国新疆及其邻区地质矿产对比研究[J]. 中国地质,2006,33 (3): 451-460. He Guoqi,Zhu Yongfeng. Comparative study of the geology and mineral resources in Xinjiang,China,and its adjacent regions [J]. Geology in China,2006,33 (3): 451-460 (in Chinese with English abstract).
姜常义,安三元. 论火成岩中钙质角闪石的化学成分及其岩石学意义[J]. 矿物岩石,1984,4(3):1-9. Jiang Changyi,An Sanyuan. On chemical characteristics of calcic amphiboles from igneous rocks and their petrogenesis significance[J]. Minerals and Rocks,1984,4(3):1-9(in Chinese with English abstract).
李锦轶,徐新. 新疆北部地质构造和成矿作用的主要问题[J]. 新疆地质,2004,22 (2): 119-124. Li Jinyi,Xu Xin. Major problems on geologic structures and metallogenesis of North Xinjiang,Northwest China [J]. Xinjiang Geology,2004,22 (2): 119-124 (in Chinese with English abstract).
三金柱,秦克章,汤中立,等. 东天山图拉尔根大型铜镍矿区两个镁铁-超镁铁岩体的锆石U-Pb定年及其地质意义[J]. 岩石学报,2010,26(2):523-532. San Jinzhu,Qin Kezhang,Tang Zhongli,et al. Precise zircon U-Pb age dating of two mafic-ultramafic complexes at Tulargen large Cu-Ni district and its geological implications[J]. Acta petrologica Sinica,2010,26(10):3027-3035 (in Chinese with English abstract).
孙涛,钱壮志,汤中立,等. 新疆葫芦铜镍矿床锆石U-Pb年代学、铂族元素地球化学特征及其地质意义[J]. 岩石学报,2010,26(11):3339-3349. Sun Tao,Qian Zhuangzhi,Tang Zhongli,et al. Zircon U-Pb chronology,platinum group element geochemistry characteristics of Hulu Cu0Ni deosit,East Xinjiang,and its geological significance[J]. Acta Petrologica Sinica,2010,26(11): 3339-3349 (in Chinese with English abstract).
汪传胜,顾连兴,张遵忠,等.东天山哈尔里克上区二叠纪高钾钙碱性花岗岩成因及地质意义[J]. 岩石学报,2009,25(6): 1499-1511. Wang Chuansheng,Gu Lianxing,Zhang Zhunzhong,et al. Petrogenesis and geological implications of the Permian high-K calc-alkaline granites in Harlik Mountains of eastern Tianshan,NW China [J]. Acta Petrologica Sinica,2009,25(6):1499-1511 (in Chinese with English abstract).
王京彬,徐新.新疆北部后碰撞构造演化与成矿[J]. 地质学报,2006,80 (1): 23-31. Wang Jingbin,Xu Xin. Post-collisional Tectonic Evolution and Metallogenesis in Northern Xinjiang,China [J]. Acta Geologica Sinica,2006,80 (1): 23-31 (in Chinese with English abstract).
夏林圻,夏祖春,徐学义,等. 天山古生代洋陆转化特点的几点思考[J]. 西北地质,2002,35 (4): 9-20. Xia Linqi,Xia Zhuchun, Xu Xueyi, et al. Some thoughts on the characteristics of Paleozoic ocean-continent transition from Tianshan mountains [J]. Northwestern Geology, 35 (4): 9-20 (in Chinese with English abstract).
夏祖春,徐学义,夏林圻,等. 天山石炭-二叠纪后碰撞花岗质岩石地球化学研究[J]. 西北地质,2005,38 (1): 1-14. Xia Zhuchun, Xu Xueyi, Xia Linqi, et al. Geochemistry of the Carboniferous-Permian post-collisinal granitic rocks from Tianshan [J]. Northwestern Geology, 2005,38 (1): 1-14 (in Chinese with English abstract).
肖庆华,秦克章,唐冬梅,等.新疆哈密香山西铜镍-钛铁矿床系同源岩浆分异演化产物-矿相学、锆石U-Pb年代学及岩石地球化学证据[J]. 岩石学报,2010,26(2):503-522. Xiao Qinghua,Qin Kezhang,Tang Dongmei,et al. Xiangshanxi composite Cu-Ni-Ti-Fe deposite belongs to comagmatic evolution product: Evidences from ore microscopy,zircon U-Pb chronology and petrological geochemistry,Hami,Xinjiang,NW China [J]. Acta Petrologica Sinica,2010,26 (2): 503-522 (in Chinese with English abstract).
徐学义,马中平,夏林圻,等.北天山巴音沟蛇绿岩斜长花岗岩锆石SHRIMP测年及其意义[J]. 地质论评,2005,51 (5): 523-527. Xu Xueyi,Ma Zhongping,Xia Linqi,et al. SHRIMP dating of plagiogranite from Bayingou ophiolite in the North Tianshan mountains [J]. Geological Review,2005,51 (5): 523-527 (in Chinese with English abstract).
徐学义,李向民,马中平,等.北天山巴音沟蛇绿岩形成于早石炭世: 来自辉长岩LA-ICPMS锆石U-Pb年龄的证据[J]. 地质学报,2006,80 (8): 1168-1176. Xu Xueyi,Li Xiangmin,Ma Zhongping,et al. LA-ICPMS Zircon U-Pb Dating of Gabbro from the Bayingou Ophiolite in the Northern Tianshan Mountains [J]. Acta geologica Sinica,2006,80 (8): 1168-1176 (in Chinese with English abstract).
张继恩,肖文交,韩春明,等.西准噶尔野鸭沟地区褶皱冲断构造的特征及意义[J]. 地质通报,2009,28 (12): 1894-1903. Zhang Jien,Xiao Wenjiao,Han Chunming,et al. Fold-and thrust-structure in Yeyagou area,western Junggar,China and its implication [J]. Geological Bulletin of China,2009,28 (12): 1894-1903 (in Chinese with English abstract).
朱永峰,何国琦,安芳. 中亚成矿域核心地区地质演化与成矿规律 [J]. 地质通报,2007,26 (9): 1167-1177. Zhu Yongfeng,He Guoqi,An Fang. Geological evolution and metallogeny in the core part of the Central Asian metallogenic domain [J]. Geological Bulletin of China,2007,26(9):1167-1177 (in Chinese with English abstract).
Andersen T. Correction of common lead in U-Pb analyses that do not report 204Pb [J]. Chemical Geology,2002,192: 59-79.
Boynton WV. Cosmochemistry of the rare earth elements [J]. Meteorite Studies Dev. Geochem.,1984,2: 63-114.
Glen RA,Vandenberg AHM. Thin-skinned tectonics in part of the Lachlan Fold Belt near Delegate,southeastern Australia [J]. Geology,1987,15: 1070-1073.
Han BaoFu,Guo ZhaoJie,Zhang ZhiCheng,et al. Age,geochemistry,and tectonic implications of a late Paleozoic stitching pluton in the North Tian Shan suture zone,western China [J]. Geological Society of America Bulletin,2010,122: 627-640.
Jahn BM,Wu F,Chen B. Granitoids of the Central Asian orogenic belt and continental growth in the Phanerozoic. Trans. R. Soc. Edinburgh [J]. Earth Sci.,2000,91: 181-193.
Jahn BM. The Central Asia Orogenic Belt and growth of the continental crust in the Phanerozoic [C]. In: Malpas J,Fletcher CJN,Ali JR,Aitchison JC (Eds.). Aspects of the tectonic evolution of China: Geol Soc Lond Spec Publ,2004,226: 73-100.
Liu Y,Gao S,Hu Z,et al. Continental and oceanic crust recycling-induced melt-peridotite interactions in the Trans-North China Orogen: U-Pb dating,Hf isotopes and trace elements in zircons of mantle xenoliths [J]. Journal of Petrology,2010,51: 537-571.
McDonough WW,Sun S-S. The composition of the Earth [J]. Chemical Geology,1995,120: 223-253.
Pearce JA,Harris NBW,Tindle AG. Trace element discrimination diagrams for the tectonic interpretation of granitic rocks [J]. J. Petrol.,1984,25: 956-983.
Peccerillo R,Taylor SR. Geochemistry of Eocene calc-alkaline volcanic rocks from the Kastamonu area,North Turkey [J]. Contrib. Mineral. Petrol.,1976,58: 63-81.
Xiao WJ,Zhang LC,Qin KZ,et al. Paleozoic accretionary and collisional tectonics of the Eastern Tianshan (China): implications for the continental growth of central Asia[J]. American Journal of Science,2004,304: 370–395.
Yuan Chao,Sun Min,Simon Wilde,et al. Post-collisional plutons in the Balikun area,East Chinese Tianshan: Evolving magmatism in response to extension and slab break-off [J]. Lithos,2010,119:269-288.
Zhou MeiFu,Lesher C Michael,Yang Zhengxi,et al. Geochemistry and petrogenesis of 270 Ma Ni-Cu-(PGE) sulfide-bearing mafic intrusions in the Huangshan district,Eastern Xinjiang,Northwest China: implications for the tectonic evolution of the Central Asian orogenic belt [J]. Chemical Geology,2004,209: 233-257.
